CMYK Fedar EPS3200 FD1900 Sublimation Printing Machine

Place of Origin China
Brand Name Fedar
Certification CE
Model Number FD1900
Minimum Order Quantity 1 Set
Packaging Details Export Wooden Crate
Delivery Time 7-10 Work Days
Supply Ability 200 Per Month
Product Details
Printhead Epson I3200-A1 Quantity 2 Pcs
Ink Color CMYK Print Width 1900mm
Ink Type Sublimation Ink,Water Based Pigment Ink RIP Software NeoStanpa,Ergosoft, Onyx,Photoprint,Maintop
Computer System Win7,Win8,Win10 Warranty 12 Months
High Light

FD1900 Sublimation Printing Machine


Fedar EPS3200 Sublimation Printing Machine


CMYK Sublimation Printing Machine

Leave a Message
Product Description
FD1900 Large Format Eco Solvent Printer
Printhead EpsonI3200-A1 Nozzle Quantity 3200
Printhead Quantity 2 Print Width 1900mm
Ink Color CMYK Print Height 2-5mm
Resolution 360*1200/360*1800/
Media Transfer Auto Taking-Up Meida Device
*Tested on linear printing without feather function
2pass 98㎡/h Drying Method Extra Dryer Device
3pass 64㎡/h Ink Supply Method Siphon Positive Pressure Ink Supply
4pass 50㎡/h Head Moisture
Auto Head Cleaning and Moisturize
6pass 32㎡/h Print Media Transfer Paper
Ink Type Sublimation Ink,
Water based Pigment Ink
Gigabit LAN
Computer System Win7, Win8, Win10(Professional) File Forms TIFF, JPG, EPS, PDF, etc.
Operate Environment Temp.:15℃-30℃, Humidity: 35℃-65℃ RIP Software NeoStanpa,Ergosoft,
Package Size 3250*960*1170mm Power Supply 210-230V, 50/60HZ, 16A
Print Power: 1000W
Dryer Power: Max.3500W
Computer Configuration Hard Disk: NTFS, C Disk Space: More than 100G, HARD Disk:WG500G GPU: ATI Discrete GPU,
Memory: 4G, CPU: Inte I5/I7, G-Ethernet
Standard Configuration Ink Level Alarm System


1. Printhead

2 Epson3200 printhead,2 pass speed can rech up to 98sqm/h.

2. Aluminum Beam and Platform

Industrial grade aluminum alloy platform guarantees long life and efficient printing.

3. Intelligent Ink Starving Alarm

Intelligent ink deficiency alert reduces the tediousness of frequently cheking ink margin and promptly reminds

to add ink to ensure the continuity of printing work.

4. Stable Media Feeding and Take-up system

Fully automatic feeding and take-up media system.Dual-motor drive offers strong power to handle non-stop

work and high-precision media movement.

5. Adopting Advanced Capping Station

Equipped with advanced intelligent auto printhead cleaning and moisturizing device,which can pump ink well

and keep the ink flow fluently.

6. Intelligent Foggy Printing&VSDT Printing

Unique two-dimension intelligent foggy and wave-foggy function,

and VSDT variable droplet technology,improve printing quality obviously.

CMYK Fedar EPS3200 FD1900 Sublimation Printing Machine 0

 CMYK Fedar EPS3200 FD1900 Sublimation Printing Machine 1

Specially Designed Car:

The height of double printheads can be arbitrarily adjusted.Anti-scratch function on both sides of the car reduces

the printhead damage caused by paper warping.

THK Mute Guide Rail:

More stable running,longer working life,lower noise,Higher resolution and fewer errors in length.

CMYK Fedar EPS3200 FD1900 Sublimation Printing Machine 2


Disc Ink Filter:

Remove the impurities in ink effectively,ensure smooth ink supply and protect the nozzle.

Large Capacity Ink Reservoirs:

Four units of 3L super large capacity ink reservoirs provide ink independently and continuously,which guarantees

the long-term continuity of ink output.


CMYK Fedar EPS3200 FD1900 Sublimation Printing Machine 3
Intelligent Air-heat Dryer:

Intelligent air-heat integrated dryer,two-stage heating,middle warm air and smart start-stop technology,ensure the

drying performance and more energy-saving at the same time.

Chinese Leadshine Motor:

High Quality Chinese most famous leadshine motor longer working life,high resolution,low length error,more stable.


CMYK Fedar EPS3200 FD1900 Sublimation Printing Machine 4

Germany IGUS Ink Chain:

Imported Germany IGUS ink chain.Super precision with low friction noise.

Pinch Roller:

The use of American fluorine rubber paper press roller to ensure the smoothness of the material when printing,

guaranteeing excellent output.


With help of heat transfer machine,printed images can be transferred to many different non-elastic material,
such as polyester and flag banner. No limit on the patterns makes it a good choice in decoration, garment and
advertising field.

CMYK Fedar EPS3200 FD1900 Sublimation Printing Machine 5

Zhengzhou New Century team had won the reputation of TOP 20 exporters in Advertising Equipment
in China and obtained more than 55 patents for the design&3patents for innovation.And have
participated in many exhibitions at home and abroad.Such as the domestic Zhengzhou exhibition,
Shanghai exhibition,Guangzhou exhibition and so on.Participating abroad is Colombia,New Delhi,
Ukraine,Thailand,Italy etc.No matter you are individual or agent, welcome to joins us !

CMYK Fedar EPS3200 FD1900 Sublimation Printing Machine 6

  • One year warranty,lifetime maintenance beyond the warranty.

  • Technical training and guidance will be provided by ten technicians who can fly to various countries at any time .

  • More than 2 million yuan were invested on after-sales every year.

  • Providing remote after-sales service support by online teachnical guidance.

Two more QC is added on export machines to guarantee the quality.Strict controlling on leadtime.
